WBZ Stabilized Soil Mixing Plant

WBZ Series Stabilized Soil Mixing Plant

We're here to help: Easy ways to get the answers you need

  • Product Information
  • parameters introduction
  • Product Details
Brief Introduction of WBZ Series Stabilized Soil Mixing Plant

WBZ series stabilized soil mixing plant is a kind of built-up plant. The form of stirring is continuous double shaft compulsory. It can mix and stir gravel-sand stabilized soil and lime stabilized soil, which can be widely used in expressway, highway, urban road, airport and stadium etc.
This stabilized soil mixing plant uses quick lime, slaked lime(water content 10-15%), soil, gravel, fly-ash and cement to produce basic materials, like lime earth stabilized soil, cement stabilized sand gravel, compressible concrete etc.
Stabilized soil mixing plant is the ideal mixing plant to produce these basic materials.




Item Model Model Model Model
Parameter WBZ300 WBZ400 WBZ500 WBZ600
Productivity 300t/h 400t/h 500t/h 600t/h
Measuring Mode Volume Measuring Volume Measuring Volume Measuring Volume Measuring
Computer Measuring Computer Measuring Computer Measuring Computer Measuring
Speed Governing Mode Frequency Control Frequency Control Frequency Control Frequency Control
Electromagnetic Speed Governing Electromagnetic Speed Governing Electromagnetic Speed Governing Electromagnetic Speed Governing
Control Mode Automatic Automatic Automatic Automatic
Manual Manual Manual Manual
Measuring Accuracy Aggregate ±3%(Volume)±2%(Electron) ±3%(Volume)±2%(Electron) ±3%(Volume)±2%(Electron) ±3%(Volume)±2%(Electron)
Powder ±2%(Volume)±1%(Electron) ±2%(Volume)±1%(Electron) ±2%(Volume)±1%(Electron) ±2%(Volume)±1%(Electron)
Water ±1%--±2% ±1%--±2% ±1%--±2% ±1%--±2%
Power 88kw 105kw 158kw 168kw
Total Weight 39t 41t 50t 54t




Features of WBZ Series Stabilized Soil Mixing Plant

Excellent performance & Advanced Technology
Rational Construction & Easy to Use
Reliable Working & Easy to Maintain
Accurate Mixing & High Productivity
