JZR Diesel Concrete Mixer

  • Capacity: 10-14m3/h--18-22m3/h
  • Charging volume: 560L-800L
  • Discharging volume: 350L-500L
  • Drum rotating-speed: 13r/min
  • Total weight: 1850kg-2200kg
  • Max. dragging speed: 20km/h

JZR series concrete mixers are self falling type bipyramid reversed discharge concrete mixing machine. The whole machine working power source is one unit of diesel engine.

We're here to help: Easy ways to get the answers you need

  • Product Information
  • parameters introduction
  • Product Details
Brief Introduction of JZR Diesel-engine Concrete Mixer

JZR series concrete mixers are self falling type bipyramid reversed discharge concrete mixing machine. The whole machine working power source is one unit of diesel engine.
In working style, clockwise rotating for concrete mixing, and anti-clockwise rotating for concrete discharging.

Technical Features of JZR Diesel-engine Concrete Mixer

1. Adopt diesel engine as working power source, can be operation in no electricity area;
2. Hydraulic tipping hopper (or wire rope hoisting) for aggregate feeding;
3. Adding a water pump for water circulation between water tank and water radiator, keep the water temperature to be stable;
4. Removing the air sucking point from the back to the front, reduce to suck the dust. It will be good to prolong the service life of the engine.



Parameters of JZR Diesel-engine Concrete Mixer

Model

JZR350W
(Wire rope hoisting tipping hopper)
JZR350H
(Hydraulic tipping hopper)
JZR500H
(Hydraulic tipping hipper)
Discharging volume 350L 350L 500L
Charging volume 560L 560L 800L
Water tank (Optional) 110L 110L 110L
Capacity 10-14m3/h 10-14m3/h 18-22m3/h
Power source Diesel engine, single cylinder, water-cooled with battery starter
Power 16HP 16HP 18HP
Drum rotating-speed 13r/min 13r/min 13r/min
Max. dragging speed 20km/h 20km/h 20km/h
Dragging 2 tyres 2 tyres / 4 tyres 2 tyres / 4 tyres
Total weight 1850kg 1790 / 1840kg 2150 /2200kg
Dimension 3100x2320x3070mm 3250x2240x3200mm 3750x2240x3800mm




Working Principle of JZR Diesel-engine Concrete Mixer

1. Assemble gear ring (rubber pad) around the external surface of the mixing drum, and the driven-shaft has small gear (riding wheels) engages the teeth of the gear ring. Meanwhile, assemble spiral mixing blades on the internal surface of the mixing drum.
2. In working style, relying on the drum rotating and inner material own gravity, the drums clockwise rotating for concrete mixing, and the anti-clockwise rotating for concrete discharging.
3. In non-working style, JZR series concrete mixer can move to other working site by trailer dragging.
